Kitchen Ecology Unit

With an increasing environmental consciousness and common global goal to lower pollution and emission, has a responsibility to contribute through the filtration of cooking fumes from commercial kitchen applications. To efficiently filter all gaseous, grease, and other particles, and an appropriate filtration of the isolated fumes from these industrial cooking appliances is essential. Ecology Unit is proposed as a second stage system of filtration, once an apt kitchen hood suitable for the desired appliance comes in.

Perfect solution for exhaust ventilation in industrial & commercial kitchen. At least 4 to 5 stages of good filtration to have a guaranteed removal performance & efficiency:

Has a grease filter to eliminate the mist and oil grease.
Has an electrostatic precipitator to remove mist, fumes, and smoke.
Bag Filter(fibre glass media) to remove fine dust particles.
Gas phase filter depending on kitchen type and pollutants.
- V-type mini pleated carbon filter with premium quality granular activated media.
- Canister type carbon filter & leak proof canister holding frame.
- Cassette type carbon filter.
- Jaf terragrid(honey comb tye)filter.
After filter will be needed for Canister and cassette type Carbon filter
Centrifugal fan and motor section.

Air Pollutants
How to maintain good IAQ?
Air Purification Equipment
Benefits
Configuration

Vapours

Vapour refers to a gas phase at a temperature where the same substance can also exist in the liquid or solid state, below the critical temperature of the substance. (For example, water has a critical temperature of 374 °C (647 K), which is the highest temperature at which liquid water can exist.)

Aerosols

Aerosol is a suspension of fine solid particles or liquid droplets, in air or another gas. The liquid or solid particles have diameter mostly smaller than 1 μm or so; larger particles with a significant settling speed make the mixture a suspension, but the distinction is not clear-cut

Smoke

Smoke is a collection of airborne solid and liquid particulates and gases. Smoke is an aerosol (or mist) of solid particles and liquid droplets that are close to the ideal range of sizes of visible light.

The naked eye detects particle sizes greater than 7 µm (micrometres). Visible particles emitted from a fire on burning are referred to as smoke. Invisible particles are generally referred to as gas or fumes.

Fumes

A gas or vapour/vapor that smells strongly or is dangerous to inhale. A material that has been vaporized from the solid or liquid state to the gas state and re-coalesced to the solid state.

Dust

Dusts are the fine particles of matter (granular solid pollutants) which arises from exhaust gases. These particulate matters suspend in the walls or surface of the air.

Pungent Odours

An odour is always caused by one or more volatilized chemical compounds. These are generally at a very low concentration. Unpleasant odours play various roles in nature, often to warn of danger, though this may not be known to the subject who smells it

Commercial Kitchen
Office Building

Commercial Kitchen

Focuses on exhaust from active kitchens during cooking through hoods. Generally, all the active commercial kitchens are fitted with hoods & duct work along with ventilation fans that are designed to remove oil grease and steamy fumes. However, odor removal targeting gaseous pollutants are often omitted at the hood design. To overcome this, a Kitchen Exhaust Purification unit consisting of different stages of filters, including Gas Phase filters, can be installed in between the ventilation fan and kitchen hood, in the duct work.

Office Building

Focuses on kitchen odors that are transmitted to air intake of air handlers from neighbouring ambient of active kitchen Exhaust. In this case, the problem is only the gaseous odor pollutant, so, can be solved by installing appropriate gas phase / odour removal filters in the air handlers that are infected by the polluted neighbour hood.

Air Purification Equipment

Best choice for Exhaust ventilation in commercial & institutional kitchens.
Utilizes effective particulate and gaseous removal filters to have proven results.
Stable & effective for many years with very minimum Maintenance & Replacements.
Modularized Design of Effective filtration stages to achieve the required removal efficiency and performance.
Ecological design with Substantial Energy Saving & Sustainability.
Modularized & Ergonomically designed to suit any type of specific requirements.

Benefits

Cleans grease, oil and smoke from kitchen exhaust air.
Reduces odor in the kitchen exhaust air.
Clean kitchen exhaust ducting and Fan.
Reduced fire hazard of kitchen.
Optional 25 to 50% re-usage of kitchen exhaust air in case of Air conditioned Kitchens, energy saving & sustainability.

Grease & Particulate Pre - Filters
Electrostatic Precipitators
High Efficiency Particulate Filters
Gas Phase / Odour Removal Filters

Grease & Particulate Pre - Filters

JAF Grease Filters, in Corrosion Resistant Aluminium construction shall effectively remove the excessive Grease & Oil generated during the cooking.

(optional) 1st or 2nd Stage pre-filters of JAF DeaKleen (or) JAF DeaMat filters can be offered to remove particulates ranging from 10 to 2.5micron.

Electrostatic Precipitators

JAF Electrostatic Precipitators (ESP), shall effectively remove fine particles, like dust and smoke, using electrostatic charge,minimally resisting the flow of air through the unit. The units shall be Self Sufficient with control schematics to have effective removal of particle sizes down 0.01μm, like smoke,mist, fumes & dust.

High Efficiency Particulate Filters

JAF MIRADEEP BORSA FG
JAF MIRADEEP BORSA
JAF MIRACEL V
JAF MIRACEL I / II
JAF LUNACEL

Any of above, or, other suitable JAF Filter Models shall be chosen & offered dependingon the type of kitchen & its usage requirements.

Gas Phase / Odour Removal Filters

JAF MIRASORB HC
JAF CANISTER MODULES
JAF CASSETTE MODULES
JAF TERRAGRID (Honey Comb) MODULES

Any of above, or, other suitable JAF Gas Phase Filter Models shall be chosen and offered depending on the type of kitchen & its usage requirements.

JAF Gas Phase Filter Modules offered in the KEU, plays a Vital Role in removing the odorous pollutants by Adsorption,Absorption & Chemisorption Techniques.
